TownSteel FCE2030 Cylindrical Lock, Rigid, Security

ELECTRONIC SPECIFICATIONS

Application
Full indoor and outdoor
The capacity of User/Office keycards per Lock
250
Credential verification time
Less than 0.5 second
Keycard maximum read/write distance
¾”
Communication
Multi-colored LED indicator and sound
Power supply
4AA battery
Battery life
Up to 2 years
Operating temperature
-31° to 151° F (-35° to 66°C)

MECHANICAL SPECIFICATIONS

Door Thickness
1-3/4”-2”
Backset
2-3/4” standard,5”optional
Trim
Outside lever is rigid in the locked position
Latch Bolt
Stainless Steel, deadlocking, ½”throw
Faceplate
1-1/8” x 2-1/4”
Strike
ASA Strike standard, 1-1/4” X 4-7/8”
Escutcheon
Wrought steel or zinc alloy, plated to match finish symbols
Lever
Cast zinc or stainless steel plated to match finish symbols
Lever Style
Sentinel (S), Quest (Q) and Gala(G)
Cylinder
? High-Security Cylinder available, 6 pins, TownSteel “L” keyway
? High-Security SFIC Core available, 7 pins, TownSteel “L” keyway
? Small Format IC with or without core available, 6 or 7 pin core, Best “A” keyway
? Schlage^® Large Format IC less core available
? Corbin^® Large Format IC less core available, for 6 pin core
Keying
KD standard, KA, MK, GMK, GGMK and construction available
Finish
US26D and US10B stocked, other upon request
Warranty
1-year limited for electronic, 5-year limited for the finish, 10-year limited for mechanical

CODE COMPLIANCE

ANSI/BHMA A156.2
A156.2-2011 Grade 1 certified
ANSI/BHMA A156.25
Meets or exceeds all applicable requirements
UL/ULC
UL 10C 3-hour rated
BAA
Meets guidelines of the Buy American Act
ADA
Meets the requirements of the Americans with Disabilities Act
RoHS
Meets requirements of EU RoHS Directive 2002/95/EC
FCC
FCC part 15 certified

Sentinel, Gala, Quest

US26D(626) and US10B(613)stocked finishes. Others upon request.
