Securitron PDB-8C8R2 2 Amp, 8 PTC Polyswitch Output with Relays, Fire Trigger

The PDB-8C8R2 from Securitron is a versatile, compact way to distribute and control power for Access Control Systems with Fire Alarm Interface. This Access Control board is an 8 position power distribution board with individual relays with input control for each output.

Features

• 8 Heavy duty Relays with individual Inputs and Status LED’s
• Each Relay Input can be Activated from Low Current Open Collector, Normally Closed or Normally Open Switch
• EOL End of Line Resistor Fire Interface Master Trigger de-energizes all Output Relays that are Enabled
• Universal 12 – 28VDC power input(Nominal 12-24VDC)
• 8C8R is Class 2 Power Limited
• Class 1 wiring required for 8F8R unless powered by a UL 294 or UL 603 or ULC S318 or ULC S533 listed power supply with class 2 output. There shall be a min of ¼ separation between power limited and non-power-limited circuits
• Available with PTC Circuit Breakers
• Each Output may be Individually Configured for:
  - Fire Trigger (FT) Enabled or (FTD) Disabled
  - N/O or N/C Option Configures the Relay Switched Output
• Each Output 1-8 has a protected, continuous Output and a Relay controlled Output
• Control Power and Main Lock Power may be Isolated (Separate Power Supplies) at Users Option
