Schlage Manually Programmable CO100993S70KP-RHO Classroom Function Surface Vertical Rod Exit Lock

Schlage Manually Programmable CO-100-993S-KP-RHO Surface Vertical Rod Exit Lock

The CO-Series is the ideal solution for customers seeking the added security and convenience of electronic access control without the cost or complexity of a fully networked system. The CO-100 is an offline lock that is manually programmable. User rights for the CO-100 are stored on the lock. Unique PIN codes can be assigned to each user. This minimizes the number of mechanical keys issued which protects the integrity of your key system. PIN codes can be easily added or deleted at anytime right at the door. The CO-100 from Schlage offers you many choices. Cylindrical, mortise, and exit trim chassis options are available as well as a wide variety of finishes and levers to suite with your existing hardware. Mechanical key override is standard and compatible with multiple cylinder types. The CO-Series is also compatible with many popular brands of exit devices. The CO-Series has been tested the highest standards in the industry to ensure quality and reliability you have come to expect from Schlage. The CO-Series is ANSI/BHMA 156.25 Grade 1 certified and UL 294 listed.*

CO-100 Offline Electronic Lock Data Sheet

Features

• • Manually programmable auto-locking exit-device operator. Compatible with the following rim panic and concealed vertical rod pushbars:
    • Von Duprin 98/99 Surface Vertical Rod
    • Von Duprin 22/22F Surface Vertical Rod
    • Falcon 25 Surface Vertical Rod

• Added security and convenience of electronic access control without the cost or complexity of a fully networked system

• Tested to highest industry standards to ensure quality and reliability

• You assign unique, sequential PIN codes (3-6 digitg) to each user (up to 500), minimizing the number of mechanical keys issued which protects the integrity of your key system

• Update users at the lock using the keypad

• Straight-forward & easy to follow installation and operating manual included

• Mechanical key override using 6-Pin Schlage standard cylinder (compatible with multiple cylinder types). You may select a different lever cylinder type, including less standard Schlage cylinder, or IC (Inter-changeable Core) cylinder prep

Specifications

• Dimensions: Exterior - 3.44" (W) x 9.46" (H) x 3.67" (D). Interior - 3.44" (W) x 10.10" (H) x 2.96" (D)

• Credential Verification Time: ≤ 1 second

• Visual/Audible Communications: Tri-colored LED’s & audible indicators

• Battery Life: Up to 2 yrs with 4AA (std. off the shelf; included)

• Operating Temperature - Exterior: -31° to 151°F (-35° to 66°C) (no battery)

• Operating Temperature - Interior: 32° to 120°F (0° to 49°C) (battery)

• Operating Humidity: 0 - 100% condensing

• Certifications: ANSI/BHMA A156.25 Grade 1, UL 294, UL 10 C, FCC Part 15, ADA
