SARGENT 10G04 10 LINE CYLINDRICAL STOREROOM LOCK

The SARGENT 10 Line is a heavy-duty cylindrical key-in-lever handle lockset exceeding by five times the ANSI 156.2 Series 4000 Grade 1 standards. The 10G04 SARGENT lock is specifically designated with storeroom function. This indicates a key operated latch with rigid outside lever, and an inside unlocked lever at all times. Individuals are ensured a quick, no special knowledge necessary exit. At over 4 million cycles, the 10 Line beats the competitor by 30%. As for abusive force, this lock endures more than two times the standard without allowing entry. The 10 line trim is designed to conform to national and state fire and handicapped requirements.1

Perfectly suited for Hospitals, Schools, Universities, Offices, Manufacturing Facilities and more…

• ANSI/BHMA Grade 1 cylindrical SARGENT lockset


• F86 Storeroom/Closet Function: Fixed outside lever. Latch operated by key only. Inside lever always unlocked


• Handing: Field reversible


• Backset: 2 3/4″ supplied


• SARGENT keyed-in cylinder with LA-15 SARGENT keyway provided in standard cylinder model


•


  Function





•


  Storeroom


•


  Door Opening
  Standard
  Locking Device
  Cylindrical Latch
  Handle Type
  Lever
  Manufacturer
  Sargent
  Door Prep
  Standard 2 1/8 in. Cross-Bore
  Finish
  Satin Chrome
  Key Override
  Standard Cylinder, Less Cylinder
