RCI

912-WBT-R

912 Series 2.4Ghz Touchless Actuator Kit, Waving Hand Icon, Includes 1 Switch and Receiver, Stainless Steel Finish

912-WBT - Double-Gang Battery Power Touch-Free Actuator by RCI

Applications: Used for Swing Doors, Sliding Doors & Glass Stone or Marble Surfaces.

Features and Benefits:

- Infrared Motion Detection Technology.
- Touch Free Activation with hand or reflective object provides clean and hygienic activation (less than 130 ms).
- Silent activation for hospitals and other noise-sensitive enviornments.
- 2.4GHz transmitter and receiver (line of site +30 meters/100ft).
- Detection distance is adjustable from 3-30 cm (1"-12").
- SPDT relay output can be used for signaling/switching automatic doors and access control (3A @ 30VDC).
- Low power consumption providing long battery life (4 "AA"-912, 2"AA"-912N,2"AAA"-912GL). Batteries not included.
- Selectable activation output beween 1.5 seconds or "latching", meaning activation "on", activation "off".
- Receiver voltage input 12-30 VDC. Receiver Dimensions: 4.8 (H) x 1.96 (W) x 1.25 (D) in.

Warranty 1 Year Limited
