Norton 5630K1-SM 689 Surface Door Operator, Double Lever Arm, Push Side, Onboard Power, 700 Switch, Hes 1006Clb, Aluminum Painted

The 5600 Series offers functionality and control at an affordable price.

Ideal for retrofit applications, the 5600 Series converts interior, non-fire rated doors for ADA compliance easily and affordably and provides a simple way to achieve touchless environments in public restrooms. Available for push or pull mounting, this unit can be operated manually or activated by wall switches, or radio frequency devices.

  • Operators for interior doors shall be products of one manufacturer and be matched in style.
  • Operator (non-fire rated doors) closing force shall be adjustable to ensure adequate closing control and shall simulate conventional door closer opening and closing forces unless the power operator motor is activated or in the event of a power outage to the operator.
  • Operators shall be non-handed and have electrically controlled backcheck, sweep, and latch with manual adjustment to set both the full open and full closed door positions.
  • Maximum door open shall be adjustable up to 95°, pull side mounting, conditions permitting.
  • Operators can be SELECTIVELY ACTIVATED (i.e. external wall switches, radio frequency devices).
  • Operators shall have input line rating of 120VAC, .6A, and include on board relay contact for interfacing with products having a rating of 24VDC at 1A.
  • Door operators shall include an external On/Off Switch to defeat powered opening cycle and an internal circuit breaker switch to interrupt input power for servicing.
  • Operators shall be ETL certified and conform to ANSI/U.L. standard 325 for automatic closing doors.
  • Door operators shall be in compliance with the requirements of the Americans with Disabilities Act (ADA) and ANSI/BHMA standard A117.1.

Arm Type: Double Lever Arm Regular

Baa Qualified: Yes

Back Check: Adjustable

Closer Size: Non-Sized

Country of Origin: Usa

Cover: Full

Degree Hold Open: Adjustable

Degree Swing: 110 Deg.

Delay: Yes

Door Size: Min. 32 In. - Max 36 In.

Door Weight: 153 Lbs.

Finish: 689/US28

Finish Description: Aluminum Painted

Hand: Non-Handed

Hold Open: Yes

Hold Open Type: Electric

Limited Warranty: 1 Year

Mounting Location: Push Side

Mounting Style: Regular

Series: 5600 Series Operators

Subtype: Door Operators

Type: Surface

Voltage: 24V
