Marks M9900VR Vertical Rods Exit Device

The Marks USA M9900 series exit device provides extreme durability for high impact applications such as schools, universities and other institutional or commercial buildings. The heavy-duty cast chassis provides superior durability, while the smooth reduced projection touchbar assembly minimizes catch hazards

Specifications

• Device Head Cover	Stainless steel
  Chassis	Steel, plated
  Mechanism Housing	Extruded aluminum
  Top Latch	Stainless Steel 37/64” (14.8mm)
  Top Strike	Included
  Bottom Latch	Stainless Steel 37/64” (14.8mm)
  Bottom Strike	Included
  Hand	Non handed
  Mounting	Machine screws standard
  Dogging feature	Allen Key Included
  Latch Bolt	3/4″ throw, stainless steel
  Dogging	Allen wrench type
  Standard Height	7’ doors
  Applications	• For use on single door or pair of doors • 1 3/4” (44 mm) door thickness standard. Specify thickness other than 1 3/4” • RHR or LHR hollow metal, wood and mineral core doors • Minimum Stile Width: 3 1/2” (89 mm)
  Finish	US32D - Satin Stainless
  Certifications	ANSI/BHMA Grade 1 Panic Exit Hardware
  Manufacturer Warranty	Marks Lifetime Mechanical Warranty
