KEYSCAN CA150

Single Door PoE Equipped Access Control Panel

Description

The CA150 is the perfect choice for smaller businesses to implement access control today with the opportunity to expand into the future. When it comes to performance, capacities and overall capability, the CA150 is comparable to the full range of Keyscan Access Control Units.

Must be a reseller to purchase this product

Features:

Equipped with a Power-over-Ethernet ready (PoE) TCP/IP module, which is designed to reduce installation time, lengthy wiring runs, and power requirements, the CA150 is the ideal solution for that single door at the far end of a building or those applications with only one critical door to be secured

The complete family of Keyscan access control units includes a 1, 2, 4, 8 and Elevator Floor Access Control panels tha can be mixed and matched to optimize system design and installation

Uses network appliance-based architecture

Supports 1 door (in and out reader capability) equipped with 1 door relay and 1 auxiliary relay (wet/dry)

Comes with 2 heavy-duty powered relays, wet or dry, (providing 500mA at 12 V DC), designed to power reader, door strike, request to exit (PIR) and many other auxiliary devices

Keyscan Access Control Units can be mixed and matched to optimize system design and installation

Easily configurable reader settings supporting Wiegand protocols

Dual multi-threaded on-board processors ensuring full panel operation even during system downloads

System status LEDs for diagnostics and troubleshooting

Communication options: TCP/IP, LAN/WAN, Internet
