Dormakaba Simplex L1000 keyless lock (Lever) Model# L1031 with Passage mode and without Key Override.

Kaba Simplex L1031 Series Keyless Pushbutton Lock with Passage Feature

for Left Hand or Left Hand Reverse Doors

Cylindrical Lever Lock, Combination Entry Only, No Key Override

Passage: Allows access without using the lock entry code Feature activated from the inside with a thumbturn or key

Features Include:

Heavy-duty cylindrical lock housing with cast front housing; unified trim plate;and fixed ADA compliant levers

Vandal resistant, solid metal pushbuttons

Factory-handed; not field reversible

Standard Finishes: Satin Chrome 26D (626), Antique Brass 05 (609)

Optional Finishes: Bright Brass 03 (605), Bright Chrome 026 (625)

Backset: 2 3⁄4" (70 mm), 2 3⁄8" (60 mm)

Latch: 1⁄2" (13 mm) throw latch; 3⁄4" (19 mm) throw latch (optional)

Strike: Standard strike plate; ASA strike plate

Fire Rating: 3-hour UL/ULC fire rating forAlabeled doors

Operation Modes:

Combination Entry and Passage (model L1031)
