Eplex E5686BWL-626-41 Electronic Pushbutton Lever Lock with Best Core Override Mortise Lock in Satin Chrome
$2,045.59
<div class="std"><ul> <li>Satin Chrome Finish</li> <li>Electronic Pushbutton Lock with dual credential capability - PIN and/or Smart card (13.56 MHz)</li> <li>PIN/Card or Dual Credential for Entry and Egress</li> <li>Extra heavy-duty Grade 1 lock with solid cast housings construction</li> <li>Compatible with MIFARE, DESFire and iCLASS Smart Cards</li> <li>Number of Users: 3,000 Access Users and (300 using LearnLok feature)</li> <li>ADA compliant lock</li> <li>Audit Capability: 30,000 Events</li> <li>American Steel Mortise (ASM) function</li> <li>With Winston lever</li> <li>American Standard Mortise Locking device with 1-1/4" (32 mm) face plate; without deadbolt</li> <li>Locks are programmed via keypad with LearnLok feature or via optional E-Plex Enterprise Software (not included)</li> <li>Non-handed operation; pre-assembled for left-hand door installations and is easily changed in the field</li> <li>UL/ULC fire door rating for "A" labeled doors up to 3 hours</li> <li>Audible and visual indicators alongwith low battery visual indicator</li> <li>Batteries are located in mortise housing that offers quick and easy battery replacement for institutions - lock data is maintained even if batteries fail</li> <li>Vandal resistant hardware with solid metal pushbuttons</li> <li>It easily installs on wood or metal doors with four bolt installation and no wiring</li> <li>Code length - it is adjustable to accept 4 to 8 digits</li> <li>Anti-tamper lockout - it is adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds</li> <li>Re-lock time - it is adjustable from 2 to 20 seconds</li> <li>Prepped for Best style removable core - SFIC. Core is not included</li> <li>Minimum Stile required: 5" (127 mm)</li> <li>Backset: Mortise- 2-3/4 inch (70 mm)</li> <li>Latch: 3/4" (19 mm)</li> <li>1 year warranty from date of installation; built-in warranty counter in lock memory</li> </ul></div>
The Eplex E5686BWL-626-41 series of Eplex Electronic Pushbutton Lock eliminate problems and costs associated with issuing, controlling and collecting keys and cards. The E-Plex 5000 Electronic Pushbutton Lock Series provides interior and exterior access by combination. Electronic Pushbutton Lock with dual credential capability - PIN and/or Smart card (13.56 MHz). Lock is scheduled to require credentials based on security and convenience requirements - PIN only, Smart card only, PIN + Smart card. Unican Kaba Ilco Simplex is the leader in top of the line security solutions that presents industrial strength combination. Electronic Pushbutton Lock with dual credential capability - PIN and/or Smart card (13.56 MHz). For a security lock, the highly weather resistant Eplex 5600 series earns an impressive Grade 1 rating from ANSI (American National Standards Institute) - this rating is the highest one they give out for quality.
Extra heavy-duty Grade 1 lock with solid cast housings construction
Compatible with MIFARE, DESFire and iCLASS Smart Cards
Number of Users: 3,000 Access Users and (300 using LearnLok feature)
ADA compliant lock
Audit Capability: 30,000 Events
American Steel Mortise (ASM) function
With Winston lever
American Standard Mortise Locking device with 1-1/4" (32 mm) face plate; without deadbolt
Locks are programmed via keypad with LearnLok feature or via optional E-Plex Enterprise Software (not included)
Non-handed operation; pre-assembled for left-hand door installations and is easily changed in the field
UL/ULC fire door rating for "A" labeled doors up to 3 hours
Audible and visual indicators alongwith low battery visual indicator
Batteries are located in mortise housing that offers quick and easy battery replacement for institutions - lock data is maintained even if batteries fail
Vandal resistant hardware with solid metal pushbuttons
It easily installs on wood or metal doors with four bolt installation and no wiring
Code length - it is adjustable to accept 4 to 8 digits
Anti-tamper lockout - it is adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
Re-lock time - it is adjustable from 2 to 20 seconds
Prepped for Best style removable core - SFIC. Core is not included
Minimum Stile required: 5" (127 mm)
Backset: Mortise- 2-3/4 inch (70 mm)
Latch: 3/4" (19 mm)
1 year warranty from date of installation; built-in warranty counter in lock memory
Extra heavy-duty Grade 1 lock with solid cast housings construction
Compatible with MIFARE, DESFire and iCLASS Smart Cards
Number of Users: 3,000 Access Users and (300 using LearnLok feature)
ADA compliant lock
Audit Capability: 30,000 Events
American Steel Mortise (ASM) function
With Winston lever
American Standard Mortise Locking device with 1-1/4" (32 mm) face plate; without deadbolt
Locks are programmed via keypad with LearnLok feature or via optional E-Plex Enterprise Software (not included)
Non-handed operation; pre-assembled for left-hand door installations and is easily changed in the field
UL/ULC fire door rating for "A" labeled doors up to 3 hours
Audible and visual indicators alongwith low battery visual indicator
Batteries are located in mortise housing that offers quick and easy battery replacement for institutions - lock data is maintained even if batteries fail
Vandal resistant hardware with solid metal pushbuttons
It easily installs on wood or metal doors with four bolt installation and no wiring
Code length - it is adjustable to accept 4 to 8 digits
Anti-tamper lockout - it is adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
Re-lock time - it is adjustable from 2 to 20 seconds
Prepped for Best style removable core - SFIC. Core is not included
Minimum Stile required: 5" (127 mm)
Backset: Mortise- 2-3/4 inch (70 mm)
Latch: 3/4" (19 mm)
1 year warranty from date of installation; built-in warranty counter in lock memory
