Corbin Russwin ML2000 Series Mortise Locks ML2051 LWA 630 Entrance or Office

ML2051 LWA 630 — Corbin Russwin Mortise Lock
Corbin Russwin ML2000 Series Grade 1 Entrance Office Mortise Lockset, LW Lever, Conventional L4 Keyway, A Rose, Satin Chrome Finish, Non-handed, 2-3/4" Backset, ASA Strike

The ML2000 Series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications. Constructed of heavy-gauge steel, the lockbody features our patented Quick Reversible latchbolt, and a 1" stainless steel deadbolt. A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.

Security

Further discourage intrusion and abuse with the ML2000VR (Vandal Resistant) series mortise lock. This lock features vandal-resistant stainless steel escutcheons with tapered edges and Torx® pin tamper resistant screws. When matched with Corbin Russwin patented high-security cylinders, any door can become a formidable barrier to intruders.

Finish: 626
Backset (in): 2-3/4"
ADA: Yes
Deadbolt Throw (in): Not Applicable
Rose/Escutcheon: Rose
Latch Throw (in): 3/4"
Cylinder Type: Conventional
Marketing Bullet 9: 3/4" Dead Latch
Door Range (Thickness): 1-3/4" - 1-3/4"
Door Handing: Non-handed
Can Be Keyed: Yes
Marketing Bullet 6: 1-1/4" x 4-7/8" ASA Strike
Grade: Grade 1
Marketing Bullet 1: Grade 1 Entrance Office Function Mortise Lockset
Base Material: Brass Bronze
Marketing Bullet 3: Conventional L4 Keyway
Keyway: L4 Keyway
Includes Cylinder(s)?: Yes
Fire Rated: Yes
Marketing Bullet 12: For Doors 1-3/4" Thick
Lever/Knob/Pull: Lever
Marketing Bullet 11: 6-5/8" X 4-1/2" Pocket Dimension
Latch Description: Dead Latch
Lever/Knob/Pull Design: LW
Projection (in): 2-1/2"
Marketing Bullet 5: 2-3/4" Backset
Marketing Bullet 14: 10 Year Warranty
Maximum Door Thickness (in): 1-3/4"
Product Warranty: 10 Year Warranty
Marketing Bullet 10: 1-1/8" x 8" Faceplate Dimension
Marketing Bullet 7: 2-1/2" Projection
Finish Description: Satin Chrome
Marketing Bullet 2: LW Lever
Rose/Escutcheon Design: A
Function: Entrance Office
Rose/Escutcheon Dimensions (in): 2-1/4"
Certification: ANSI A156.13, Series 1000, Grade 1, ANSI A117.1 (ADA)
Strike Description: ASA Strike
Pocket Dimensions: 6-5/8" X 4-1/2"
Strike Dimensions: 1-1/4" x 4-7/8"
Strike Number: SA118
Minimum Door Thickness (in): 1-3/4"
Series: ML2000 Series
Parent Manufacturer: Assa Abloy
Marketing Bullet 13: ANSI A156.13, Series 1000, Grade 1, ANSI A117.1 (ADA)
Marketing Bullet 4: A Rose
Marketing Bullet 8: 2-1/4" Rose Dimension
