AltronixSTRIKEIT4 Low Current Locking Device Power Controller / Power Supply/Charger, 24VDC @ 4A in-Rush, Aux. Output, FAI, 115VAC /230VAC, BC300 Enclosure
$358.62
<div class="std">StrikeIt1V dual channel Panic Device Power Controller is designed to handle the high current surge panic hardware locking devices demand. Each lock output has an adjustable relock delay timer. It will control a pair of doors simultaneously or independently control two individual doors. It has a follower relay for each output to trigger external relays, ADA push plate switches, etc. Delayed follower relays control automatic door operators for doors that are always locked or for doors that are unlocked during the business day. In addition, two un-switched auxiliary voltage outputs are provided for powering card readers, keypads, REX PIRs, electronic timers, relays, etc. A configurable FACP interface will either provide power or remove power to the lock outputs when activated. LED status indicators are provided to monitor AC power, FACP status and for lock output wiring supervision. Intelligent logic provides protection against accidental shorting of lock outputs.</div>
Two (2) Normally Open (N.O.) trigger inputs (Input 1 and Input 2).
FACP Normally Closed (N.C.) input.
Two normally open ADA inputs for a special mode of interfacing with automatic door operators.
Outputs
Two (2) 19.8VDC-26.4VDC rated individually controlled lock outputs configurable for fail-secure or fail-safe electronic locking hardware for applications with battery back-up. 24VDC-26.4VDC rated for applications without battery back-up (US applications only). Current rating 2A combined.
One (1) 19.8VDC-26.4VDC @ 0.8A rated filtered regulated auxiliary output for applications with battery back-up, 24VDC-26.4VDC @ 0.8A rated for applications in the US not requiring battery back-up. Not affected by the FACP trigger.
One (1) 12VDC filtered regulated auxiliary output rated 0.5A. Not affected by the FACP trigger.
Two (2) follower Normally Open relay outputs for controlling ADA actuators/accessories rated 28VDC @ 0.5A.
Two momentary door operator activation relay outputs.
Trouble relay output indicating low AC voltage trouble and battery trouble.
Battery Backup
Battery leads included.
When 7AH batteries are used, battery capacity for emergency stand-by is 30 minutes.
Built-in charger for sealed lead acid batteries.
Maximum charge current 650mA.
Automatic switch over to stand-by battery when AC fails.
Visual Indicators
Green AC Power LED indicates AC presence.
Red trigger output LEDs indicate panic device status / opened (activated, short circuit).
Green Fire Alarm Interface (FAI) LED indicates FACP interface is activated.
Red Battery LED indicates low battery during AC failure and battery test.
Green AC status LED indicates a loss of AC power.
Fire Alarm Disconnect
Normally Closed FACP trigger input.
Programmable Fire Alarm Disconnect options:
Removes power to outputs and disables delayed follower relays.
Connects power to lock outputs and enables delayed follower relays.
Temperature
Operating 0° C to 49° C (32° F to 120° F).
Storage - 20° C to 70ºC ( - 4° F to 158° F).
Relative Humidity 85% +/- 5%.
BTU/Hr (approx.): 120 BTU/Hr.
Enclosure:
Wall mount enclosure for indoor use.
Dimensions 13"W x 13.5"H x 3.25"D (330 mm W x 343 mm H x 83 mm D).
1/2" and 3/4" combination knockouts.
Weights (approximate):
Product Weight: 6.25 Lbs. (2.83 kg).
Shipping Weight: 7.15 Lbs. (3.24 kg).
StrikeIt1V dual channel Panic Device Power Controller is designed to handle the high current surge panic hardware locking devices demand. Each lock output has an adjustable relock delay timer. It will control a pair of doors simultaneously or independently control two individual doors. It has a follower relay for each output to trigger external relays, ADA push plate switches, etc. Delayed follower relays control automatic door operators for doors that are always locked or for doors that are unlocked during the business day. In addition, two un-switched auxiliary voltage outputs are provided for powering card readers, keypads, REX PIRs, electronic timers, relays, etc. A configurable FACP interface will either provide power or remove power to the lock outputs when activated. LED status indicators are provided to monitor AC power, FACP status and for lock output wiring supervision. Intelligent logic provides protection against accidental shorting of lock outputs.
